Denon AVR-1613 Service Manual

91
SMPS
(FOIL SIDE)
Sec.
Pri.
Pri.
Sec.
Sec.
Pri.
Sec.
Pri.
L N
Q6002
R6033R6032R6031
R6030
R6029
R6028
R6027
C6005 C6006
R6025
R6012
R6013
R6023
R6006
R6024
R6020
R6014
R6011
R6026
R6019
R6022
C6025
C6024
C6022
C6021
C6020
C6014
C6012
C6009 C6007
C6015
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
