Denon AVR-1912 Service Manual

136
Ref. No. Part No. Part Name Remarks Q'ty New
P16 8U6331008500D PCB HDMI ASSY 1912BKE2,1912BKEA 7025HK1015055 1 *
P16 nsp PCB HDMI ASSY 1912SPE1C 7025HK1015025 1 *
1 963416013480D WINDOW DISPLAY 1912BKE3 5077213153020S 1 *
1 963416013460D WINDOW DISPLAY
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
5077213153000S 1 *
2 963412000570D KNOB FUNCTION(KD) BK 5080211761000SZ 1
2 943412100640D KNOB FUNCTION SP CBN1A254C73 1 *
3 00D9630362109 BADGE DENON BK 5630210028300S 1
3 00D9630362202 BADGE DENON SP 5630210028400S 1
4 963402013360D PANEL FRONT 1912BKE3 3067215191000S 1 *
4 963402013350D PANEL FRONT 2112CIBKE3 3067215201000S 1 *
4 963402013380D PANEL FRONT 1912BKE2,1912BKEA 3067215201110S 1 *
4 963402013390D PANEL FRONT 1912SPE1C 3067215201200S 1 *
5 963411002810S BUTTON 4KEY 1912BKE3 5097213731000S 1
6 00D9630137807 LENS STANDBY 3710210503000S 1
7 963411002820S BUTTON-ASSY STANDBY(KD) BK 5098212361000SZ 1
7 00D9630221904 BUTTON-ASSY STANDBY SP 5097212368030SZ 1
8 nsp PLATE EARTH USB 1912BKE3 4470212106000S 1 *
8 nsp PLATE EARTH USB
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
4470212116000S 1 *
9 00D9630365002 BUTTON WIN 3KEY BK 5097213371000S 2
9 00D9630365301 BUTTON WIN 3KEY SP 5097213371110S 2
10 00D9630365404 BUTTON WIN 6KEY 1912BKE3 5097213361000S 1
10-1 963411003400D BUTTON WIN 3KEY C
2112CIBKE3,1912BKE2,
1912BKEA
5097213831000S 1
10-1 963411003690D BUTTON WIN 3KEY C 1912SPE1C 5097213831100S 1
11 963411013450D BUTTON 8KEY 1912BKE3 5097214661000S 1 *
11 963411013430D BUTTON 8KEY
2112CIBKE3,1912BKE2,
1912BKEA
5090214671000S 1 *
11 963411013440D BUTTON 8KEY 1912SPE1C 5090214671100S 1 *
12 963419100040D COVER RCA 1912BKE3 4317215141010S 1 *
12 963419013410D COVER RCA
2112CIBKE3,1912BKE2,
1912BKEA
4317215361000S 1 *
12 963419013420D COVER RCA 1912SPE1C 4317215361100S 1 *
13 963412000560D KNOB VOLUME(KD) BK 5080211751000SZ 1
13 943412009850D KNOB VOLUME SP CBN1A249C73 1 *
20 nsp CUSHION SCREW 4050213025000S 4
21 nsp CUSHION SIDE 4050213095000S 2
22 00D9630214607 CUSHION FOOT 4050211295000S 4
23 963407100030D FOOT 1912BKE3 4000210641000S 4 *
23 963407100200D FOOT
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
4000210261000S 4 *
24 nsp CHASSIS MAIN 1912BKE3 3200213506400S 1
24 nsp CHASSIS MAIN
2112CIBKE3,1912BKE2,
1912BKEA,1912SPE1C
3200213506500S 1 *
25 nsp SUPPORTER PCB 4070001601010S 3
26 nsp SUPPORTER P.C. 4070210192000S 1
NOTE :
When replacing the 1912SPE1C PCB HDMI ASSY, use the 1912BKE2/1912BKEA PCB HDMI ASSY (8U6331008500D).
Please change the parts when changing 1912BKE2/1912BKEA PCB HDMI ASSY to 1912SPE1C. (Refer to the table below)
Please refer to parts 127 , 128 page. (SCHEMATIC DIAGRAMS : 22/26, 23/26)
R701(22/26) R702(22/26) R709(22/26) R710(22/26) R773(23/26) R776(23/26)
1912BKE2/1912BKEA OPEN OPEN OPEN OPEN OPEN 0
1912SPE1C 470k 470k 470k 470k 10k 10K
After replacing the PCB HDMI ASSY in 1912SPE1C, overwrite the rmware with the newest E1C version rmware.
(Refer to "PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE" (45 page).)
[ IC11 ] [ IC18 ] [IC22] [ IC41 ] [U7] (Refer to parts list of "PCB HDMI ASS'Y" (188 page).)

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
