Denon AVR-1912 Service Manual

173
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
1912E3 : U.S.A. & Canada model 1912E2 : Europe model 1912EA : Australia model
1912E1C : China model 2311CIE3 : U.S.A. & Canada model
BK : Black model SP : Premium Silver model
PCB 7CH_AMP ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q417 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q461 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q463 00D2710318909 TR 2SA 2N5401S J520254010010S
Q466 00D2730479909 TR 2SC 2N5551S J522255510010S
Q467,468 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q472 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q473 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q475 00D2710318909 TR 2SA 2N5401S J520254010010S
Q478 00D2730479909 TR 2SC 2N5551S J522255510010S
Q479,480 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q484 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
D402-404 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D408-410 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D414-416 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D420-422 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D426-428 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D432-434 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D438-440 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD401 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD402,403 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD404 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD405,406 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD407 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD408,409 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD410 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD411,412 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
s

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
