Denon AVR-1912 Service Manual

174
Ref. No. Part No. Part Name Remarks Q'ty New
ZD413 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD414,415 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD416 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD417,418 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD419 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD420,421 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R404 nsp R,FIXED 1WJ-5.6K N113135656220S
R406 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R408 nsp R,FIXED 1WJ-5.6K N113135656220S
R415 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R424,425 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R430,431 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R434 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R439 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R441 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R443 nsp R,METAL FILM 47-J,1W C060047065060S
R445 nsp R,FIXED 1WJ-5.6K N113135656220S
R450 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R451 nsp R,FIXED 1WJ-5.6K N113135656220S
R458 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R467,468 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R474,475 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R478 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R483 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R485 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R487 nsp R,METAL FILM 47-J,1W C060047065060S
R489 nsp R,FIXED 1WJ-5.6K N113135656220S
R493 00D9630337908 R,METAL 33-J,1W FLAME RETARDANT C060033065050S
R494 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R495 nsp R,FIXED 1WJ-5.6K N113135656220S
R502 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R511,512 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R517,518 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R521 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R526 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R528 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R530 nsp R,METAL FILM 47-J,1W C060047065060S
R534 nsp R,FIXED 1WJ-5.6K N113135656220S
R537 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R538 nsp R,FIXED 1WJ-5.6K N113135656220S
R545 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R551 00D9639005639 R,METAL FILM 100-J,1W FLAME RETARDANT C060010165060S
R554,555 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R561,562 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R564 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R569 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R571 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R573 nsp R,METAL FILM 47-J,1W C060047065060S
R577 nsp R,FIXED 1WJ-5.6K N113135656220S
R580 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R581 nsp R,FIXED 1WJ-5.6K N113135656220S
R588 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R597,598 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R603,604 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R607 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R612 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R614 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R616 nsp R,METAL FILM 47-J,1W C060047065060S
R620 nsp R,FIXED 1WJ-5.6K N113135656220S
R623 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R624 nsp R,FIXED 1WJ-5.6K N113135656220S
R631 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R640,641 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R646,647 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
