Denon AVR-1912 Service Manual

175
Ref. No. Part No. Part Name Remarks Q'ty New
R650 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R655 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R657 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R659 nsp R,METAL FILM 47-J,1W C060047065060S
R663 nsp R,FIXED 1WJ-5.6K N113135656220S
R666 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R667 nsp R,FIXED 1WJ-5.6K N113135656220S
R674 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R683,684 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R689,690 00D9630345903 R,FIXED 2WJ-0.47 FLAME RETARDANT N113136647820S
R694 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R698 963125012630S R,METAL FILM 22-J,1W FLAME RETARDANT C060022065050S
R700 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R702 nsp R,METAL FILM 47-J,1W C060047065060S
VR401-407 963161012400S
VR,SEMI CARBON
EVN-DCAA03B 1KB
C541102315000S
CAPACITORS GROUP
C401 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C403 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C404 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C405 nsp C,CERAMIC 100PF-J/50V D010101167160S
C406 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C407 00D9630234506 C,ELECT 47UF-M/50V (Pb Free)
1912E3,1912E1C,
2112CIE3
D040470087070S
C407 00D2544574919 C,ELECT 47UF-M/50V RA3 1912E2,1912EA D040470087330S
C408 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C410 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C412 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C413 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C415,416 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C418 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C419 00D9630324005 C,ELECT 100UF-M/100V D04010108C240S
C420 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C421 nsp C,CERAMIC 100PF-J/50V D010101167160S
C422 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C423 00D9630234506 C,ELECT 47UF-M/50V (Pb Free)
1912E3,1912E1C,
2112CIE3
D040470087070S
C423 00D2544574919 C,ELECT 47UF-M/50V RA3 1912E2,1912EA D040470087330S
C424 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C426 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C428 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C429 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C434 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C436 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C437 nsp C,CERAMIC 100PF-J/50V D010101167160S
C438 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C439 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C440 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C442 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C444 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C445 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C450 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C452 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C453 nsp C,CERAMIC 100PF-J/50V D010101167160S
C454 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C455 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C456 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C458 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C460 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C461 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C466 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C468 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C469 nsp C,CERAMIC 100PF-J/50V D010101167160S
C470 nsp C,CERAMIC SL220PF-J/500V D00022106D051S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
