Denon AVR-1912 Service Manual

176
Ref. No. Part No. Part Name Remarks Q'ty New
C471 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C472 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C474 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C476 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C477 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C479,480 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C482 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C484 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C485 nsp C,CERAMIC 100PF-J/50V D010101167160S
C486 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C487 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C488 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C490 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C492 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C493 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C498 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C500 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C501 nsp C,CERAMIC 100PF-J/50V D010101167160S
C502 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C503 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C504 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C506 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C508 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C509 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C511,512 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C513,514 00D9630338402 C,ELECT 330UF-M/6.3V D040331081050S
C515 00D9630324607 C,ELECT 47UF-M/10V (Pb Free) D040470082060S
OTHERS PARTS GROUP
BKT400 nsp BRACKET 0.8t/SCREW 4010210196100S
CN404 nsp CN.WIRE 240MM/5P L025241052620S
CP401 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP402 nsp CN.WAFER 5P 5267-05A L102526700500S
CP403 nsp CN.WAFER 10P STRAIGHT L101200101010S
CP405 nsp CN.WAFER 3P 5267-03A L102526700300S
G400 nsp CN.WIRE 60MM/1P L025600012040S
G402 nsp CN.WIRE 60MM/1P L025600012040S
J538 nsp CN.WIRE 1P L045061000050S
TP401-407 nsp CN.WAFER 3P L101200100320S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
