Denon AVR-1912 Service Manual

185
PCB AUDIO_VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 963239000650S IC R2A15218FP J084152180010S
IC806 963233100020S IC TC4052BFT J040405205510S *
IC821 232810005504S IC BD7628F-E2 J127762800010S
IC822 00D2623445901 IC TC4051BFT J040405105510S
IC823 232810005504S IC BD7628F-E2 J127762800010S
IC825 963239003470S IC NJM2586AM J171258600010S
IC826 963233100020S IC TC4052BFT J040405205510S *
Q821 943214500030S TR 2SC INC2001AC1 CVTINC2001AC1
Q822,823 943215500020S TR 2SA RT1P141C CVTRT1P141C
Q836 943215500020S TR 2SA RT1P141C 2112CIE3 CVTRT1P141C
Q837 943214500030S TR 2SC INC2001AC1 2112CIE3 CVTINC2001AC1
Q842 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q844 943216500020S TR 2SC RT1N141C 2112CIE3 CVTRT1N141C
Q846 943215500020S TR 2SA RT1P141C 2112CIE3 CVTRT1P141C
Q847 943214500030S TR 2SC INC2001AC1 2112CIE3 CVTINC2001AC1
Q855 963212500030S TR 2SA ISA1530AC1 J520015301210S *
Q856-858 943216500020S TR 2SC RT1N141C CVTRT1N141C
Q859 963212500030S TR 2SA ISA1530AC1 J520015301210S *
Q860 963216500060S TR 2SC RT1N144C J522101441210S
D800,801 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D828,829 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D841 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D848-851 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD800 00D2760760905 D,ZENER MTZJ3.6B-0.5W/5MA K06003R644520S
CAPACITORS GROUP
C800,801 00D9630234205 C,ELECT 10UF-M/50V
1912E3,1912E1C,
2112CIE3
D040100087070S
C800,801 963134501230S C,ELECT 10UF-M/50V RA3 1912E2,1912EA D040100087380S *
C802-807 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C808 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C809,810 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C811 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C812,813 nsp C,CERAMIC 330PF-J/50V D010331167160S
C823 00D2544583942 C,ELECT 10/50(ROB ) 1912E2,1912EA D040100087140S
C825 00D2544583942 C,ELECT 10/50(ROB ) 1912E2,1912EA D040100087140S
C826 nsp C,CERAMIC 330PF-J/50V D010331167160S
C828 nsp C,ELECT 47UF-M/16V
2112E3,19112E3,
1912E1C
D040470083080S
C828 00D2544577932 C,ELECT 47/16(RA3) 1912E2,1912EA D040470084330S
C829 nsp C,CERAMIC 330PF-J/50V D010331167160S
C830 nsp C,ELECT 47UF-M/16V D040470083080S
C832 nsp C,ELECT 47UF-M/16V
2112E3,19112E3,
1912E1C
D040470083080S
C832 00D2544577932 C,ELECT 47/16(RA3) 1912E2,1912EA D040470084330S
C834 nsp C,CERAMIC 330PF-J/50V D010331167160S
C835,836 nsp C,ELECT 47UF-M/16V D040470083080S
C837 nsp C,CERAMIC 330PF-J/50V D010331167160S
C838,839 nsp C,ELECT 47UF-M/16V D040470083080S
C840 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C842 nsp C,CERAMIC 330PF-J/50V D010331167160S
C844,845 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C846 nsp C,ELECT 47UF-M/16V D040470083080S
C847 nsp C,CERAMIC 330PF-J/50V D010331167160S
C850,851 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C854 nsp C,CERAMIC 330PF-J/50V D010331167160S
C856 nsp C,CERAMIC 330PF-J/50V D010331167160S
C861 nsp C,CERAMIC 330PF-J/50V 2112CIE3 D010331167160S
C862-864 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C865 00D9630224503 C,ELECT 22UF-M/50V 2112CIE3 D040220087060S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
