Denon AVR-1912 Service Manual

186
Ref. No. Part No. Part Name Remarks Q'ty New
C866 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) 2112CIE3 D040R10087080S
C867 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C868,869 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C870 nsp C,CERAMIC 100PF-J/50V D010101167160S
C871 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C896 nsp C,CERAMIC 330PF-J/50V 2112CIE3 D010331167160S
C897-899 00D9630224503 C,ELECT 22UF-M/50V 2112CIE3 D040220087060S
C918 nsp C,CERAMIC 100PF-J/50V 2112CIE3,1912E3 D010101167160S
C919 nsp C,CERAMIC 33PF-J/50V
1912E2,1912EA,
1912E1C
D010330167160S
C921 nsp C,CERAMIC 100PF-J/50V 1912E2,1912EA D010101167160S
C925 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C926 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C927 nsp C,ELECT 47UF-M/16V D040470083080S
C928 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C929 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C930,931 nsp C,CERAMIC 100PF-J/50V 2311E3,1912E3 D010101167160S
C932 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C933 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C935 nsp C,CERAMIC 100PF-J/50V
1912E2,1912EA,
1912E1C
D010101167160S
C936 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C937 nsp C,CERAMIC 100PF-J/50V 1912E2,1912EA D010101167160S
C938 nsp C,CERAMIC 0.1UF-K/50V 2112CIE3,1912E3 D011104577160S
C939,940 nsp C,CERAMIC 100PF-J/50V 2112CIE3,1912E3 D010101167160S
C941 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C943 nsp C,CERAMIC 100PF-J/50V
1912E2,1912EA,
1912E1C
D010101167160S
C944 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C945 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C946 nsp C,ELECT 47UF-M/16V D040470083080S
C947 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C948,949 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C950 nsp C,ELECT 47UF-M/16V D040470083080S
C951 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C952 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C953 nsp C,CERAMIC 100PF-J/50V
1912E2,1912EA,
1912E1C
D010101167160S
C959 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C960 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C971 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C974,975 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C999,1000 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1002 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1006,1007 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1008 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1009-1011 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1012 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1013 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1014 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1015-1017 nsp C,CERAMIC 68PF-J/50V D010680167160S
C1018 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1019 nsp C,CERAMIC 220PF-J/50V D010221167160S
C1020 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1021 nsp C,ELECT 47UF-M/16V D040470083080S
C1022 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1117,1118 nsp C,FILM 0.0047UF 1912E2,1912EA D02047206C060S
C1119,1120 nsp C,FILM 0.0082UF 1912E2,1912EA D02082206C060S
OTHERS PARTS GROUP
BD803 nsp COIL,BEAD CBW160808U121T D340160811210S
CN12 nsp CN.FPC 19P TWG-P19P-A1 L131019000010S
CN112,113 nsp CN.WAFER 19P C125Z2-19 L109012521910S
CN114 nsp CN.WAFER 21P C125Z2-21 L109012522110S
CN115 nsp CN.WAFER 17P C125Z2-17 L109012521710S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
