Denon AVR-1912 Service Manual

178
Ref. No. Part No. Part Name Remarks Q'ty New
C10 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C12 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C13 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C15 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C17 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C18 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C22 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C25 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C27 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C30 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C33 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C36 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C39 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C42 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C45 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C53 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C54 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C55 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C56 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C57 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C58 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C59 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C60 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C61 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C63 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C64 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C65,66 nsp C,FILM 0.1UF-K/250V D02010407H080S
C67,68 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C100 nsp C,FILM 0.1UF-K/275V D02110407H010S
C102 963134010200S C,ELECT 100UF-M/400V D04110108K000S
C103 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
z
C104,105 963134011730S
C,CERAMIC
DE1B3KX471KB4BL01 AC250V
D00847127H010S
C106-108 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C110 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C111 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C112 963134010190S C,ELECT 10UF-M/50V D041100087050S
C113 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
z
C115 963132011930S
C,CERAMIC
DE1E3KX222MB4BL01 AC250V
D00822248H010S
C116 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
z
C117 963132011940S
C,CERAMIC
DE2F3KY103MB3BM02 AC250V
D008103589010S
C118 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C119 963134010210S C,ELECT 47UF-M/25V D041470084050S
C120-123 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C131 963132011940S
C,CERAMIC
DE2F3KY103MB3BM02 AC250V
1912E2,1912EA,
1912E1C
D008103589010S
C133 963132011940S
C,CERAMIC
DE2F3KY103MB3BM02 AC250V
1912E2,1912EA,
1912E1C
D008103589010S
OTHERS PARTS GROUP
BKT1-3 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT100 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT101 nsp BRACKET SCREW 4010210196000S
CLAMP3 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN1 nsp CN.WIRE 230MM/5P L025231052650S
CN2 nsp CN.WIRE 160MM/3P L025161032050S
CN3 nsp CN.WIRE 170MM/10P L025171102620S
CP1 nsp CN.WAFER 7.92MM 35328-0360 L108353280360S
CP12 nsp CN.FPC 1.25MM 19P 127301119K2 L131019100010S
CP22 nsp CN.WAFER 5P TUC-P05P L101100040510S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
