Denon AVR-1912 Service Manual

181
Ref. No. Part No. Part Name Remarks Q'ty New
BKT401 nsp BRACKET 0.8t/SCREW 2112CIE3 4010210196100S
BKT402 nsp BRACKET 0.8t/SCREW
1912E3,1912E2,
1912EA,1912E1C
4010210196100S
CN13A nsp CN.WIRE 120MM/10P L025121102620S
CN13B nsp CN.WIRE 120MM/4P. L025121042620S
CN14 nsp CN.WAFER 23P C125Z2-23 L109012522310S
CN100 nsp CN,WAFER 13P C125Z2-13 L109012521310S
CN101 nsp CN,WAFER 9P C125Z2-09 L109012520910S
CN401 nsp CN,WAFER 9P 2112CIE3 L109012520910S
CN402 nsp CN,WAFER 11P 2112CIE3 L109012521110S
CP3 nsp CN,WAFER 13P C125Z1-13 L109012511310S
CP5 nsp CN,WAFER 19P C125Z1-19 L109012511910S
CP8 nsp CN,WAFER 19P C125Z1-19 L109012511910S
CP9,10 nsp CN,WAFER 13P C125Z1-13 L109012511310S
CP11 nsp CN.WAFER 33P C125Z1-33 L109012513310S
CP13A nsp CN.WAFER 10P 20010WR-10A00 L101200101020S
CP13B nsp CN.WAFER 4P 20010WR-04 L101200100420S
CP100 nsp CN.WAFER 13P C125Z1-13 L109012511310S
CP101 nsp CN.WAFER 9P C125Z1-09 L109012510910S
CP102 nsp CN.WAFER 4P 5267-04A L102526700400S
CP104 nsp CN.WAFER 3P 5267-03A L102526700300S
CP112,113 nsp CN,WAFER 19P C125Z1-19 L109012511910S
CP114 nsp CN,WAFER 21P C125Z1-21 L109012512110S
CP115 nsp CN,WAFER 17P C125Z1-17 L109012511710S
CP401 nsp CN,WAFER 9P 2112CIE3 L109012510910S
CP402 nsp CN,WAFER 11P 2112CIE3 L109012511110S
z
F104 963652500120S FUSE T1.25A/250V
1912E2,1912EA,
1912E1C
N751501251160S *
z
F105 963652010500S FUSE T1.6A/250V N751501601160S
z
F106 963652010500S FUSE T1.6A/250V N751501601160S
F104A,104B nsp HOLDER,FUSE CLIP
1912E2,1912EA,
1912E1C
G645000050010S
F105A,105B nsp HOLDER,FUSE CLIP G645000050010S
F106A,106B nsp HOLDER,FUSE CLIP G645000050010S
JACK404 00D2051305008 CN.WAFER 9P 2112CIE3 L103090090030S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
