Denon AVR-1912 Service Manual

196
Ref. No. Part No. Part Name Remarks Q'ty New
F1 00D2790055907 SW,POLY MICROSMD175F G300017500010S
JACK1-7 963643100120S HDMI CONNECTOR 19P L109100190160S *
JACK8,9 00D9630244703 JACK,D3.5 EARPHONE 2112CIE3 G40130802000YS
JK1 963643003580S TER,RCA 1PIN G600107C0020YS
JK2 00D9630294601 JACK,D3.5 EARPHONE G40100350000YS
L3-8 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L10 nsp COIL,CHIP DLW21SN181SQ2L D311201211810S
L12 nsp R,CHIP THICK 0-J,1/10W C200000060200S
L14 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L15 nsp COIL,BEAD CBW160808U121T D340160811210S
L16 nsp COIL,CHIP DLW21SN900HQ2L D311201219000S
L17,18 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L19 nsp COIL,CHIP DLW21SN900HQ2L D311201219000S
L20-24 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L27,28 nsp R,CHIP 0-J, 1/16W C20000006M160S
X1 141810044504S
CRYSTAL CHIP
FCX-04(28.63636MHz)
E80528R636380S
X2 963141010990S CRYSTAL CHIP FCX-04(24MHz) E80524R000080S
X3 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S
X4 943141100020S CRYSTAL CHIP FCX-04(21.875MHz) COX21875I070SR
X5 00D3991038900 CRYSTAL CHIP FCX-03(12MHz) E805120000020S
XTAL1 141810044504S
CRYSTAL
CHIP FCX-04(28.63636MHz)
E80528R636380S
CX1 nsp CN.WAFER 5P SMW250-5P L102050010040S
CX4 nsp CN.FPC 40P 10022HS-40C L130100220400S
FB1-5 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB6,7 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB8 nsp COIL,BEAD CBW160808U121T D340160811210S
FB9,10 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB11,12 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB13,14 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB15,16 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB17,18 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB19,20 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB21,22 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB23,24 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB29-36 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
FB37-44 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB45-80 nsp R,CHIP 0-J, 1/16W C20000006M160S
FB81-84 nsp R,CHIP THICK 0-J,1/10W C200000060200S
FB85-103 nsp R,CHIP 0-J, 1/16W C20000006M160S
FB105-145 nsp R,CHIP 0-J, 1/16W C20000006M160S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
