Denon AVR-2105 Operating Instructions

Dolby Pro Logic
II
x (Pro Logic
II
) mode
2
Select the Dolby Surround Pro Logic IIx mode.
LOGICII
Light
(Main unit) (Remote control unit)
3
Play a program source with the mark.
• For operating instructions, refer to the manuals of the respective components.
5, 74, 61 2
4
5, 7
1
9
5, 7
2
6
6
STANDARD
4
Select the surround parameter mode.
1
Select the function to which the component you want to play
is connected.
Example: DVD
FUNCTION
(Main unit) (Remote control unit)
Display
To perform this operation from the remote control unit, check that
the mode selector switch is set to “AUDIO”.
• The Dolby Pro Logic II indicator lights.
The Dolby Surround Pro Logic
IIx Cinema or Music mode can
be chosen directly by pressing
the CINEMA or MUSIC button
on the remote control unit
during playback in the Dolby
Surround Pro Logic IIx mode.
To play in the PL IIx mode, set “S. BackSp” at the Speaker Configuration setting to “1Sp” or “2Sp”.
To play in the PL IIx mode, set “Surround Back” at the Power Amp Assign setting.
SURROUND
PARAMETER
(Main unit)
(Remote control unit)
Display
50
ENGLISH

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
