Page #5 background imageLoading...
Page #5 background image
5
AVR-2807
CAUTION IN SERVICING
Initializing AV SURROUND RECEIVER
AV SURROUND RECEIVER initialization should be performed
when the µcom, peripheral parts of µcom, and Digital P.W.B. are
replaced.
1. Switch off the unit.
2. Hold the following NIGHT button and PURE DIRECT button,
and switch on the unit.
3. Check that the entire display is flashing with an interval of
about 1 second, and release your fingers from the 2 buttons
and the microprocessor will be initialized.
Note:If step 3 does not work, start over from step 1.
All user settings will be lost and this factory setting will
be recovered when this initialization mode.
So make sure to memorize your setting for restoring
after the initialization.
サービス時の注意事項
AVサラウンドアンプの初期化について
マイコンやマイコン周辺部品、Digital 基板等を交換した場合は、
AV サラウンドアンプの初期化を行って下さい。
1. オン/オフボタンを OFF にします。
2. NIGHT ボタンと PUREDIRECT ボタンを同時に押しながら、
オン/オフボタンを押して ON にします。
3. ディスプレイ表示が約 1秒間隔で点滅するのを確認後、
2つのボタンから指を離します。
*マイコンが初期化されます。
注意 :・上記 3 の状態にならない場合は、もう一度操作 1
らやり直してください。
・初期化を行うとお客様が設定した内容が工場出荷状
態に戻りますので、あらかじめ設定内容を控えてお
き初期化後再設定してください。

Other manuals for Denon AVR-2807

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-2807 and is the answer not in the manual?

Denon AVR-2807 Specifications

General IconGeneral
Number of Channels7.1
HDMI Inputs2
HDMI Outputs1
Component Video Inputs3
Component Video Outputs1
Dolby DigitalYes
DTSYes
Frequency Response10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion0.05%
Input Sensitivity200 mV
Signal-to-Noise Ratio100 dB
Speaker Impedance6-16 ohms
Tuner TypeAM/FM
Power Output110W per channel
Digital Audio Inputs2 coaxial
Auto SetupAudyssey MultEQ
Multi-roomYes
Width434 mm
Height171 mm
Dimensions434 x 171 x 414 mm
