AVR-2807
DOCUMENTS FOR WEEE
Details of Recycle Parts
＊You have to remove the parts that marked “WEEE Mark ◆ " when the recycling processing. (E1C:China model only)
Ref. No.
WEEE
MARK
Part Name MATERIAL Q'ty
1-1
◆
1U-3700-1:MAIN CPU UNIT COMPLEX 1
1-2
◆
1U-3700-2:DIGITAL IN UNIT COMPLEX 1
1-3
◆
1U-3700-3:EXT IN/PREOUT UNIT COMPLEX 1
1-4
◆
1U-3700-4:PRE CONNECT2 UNIT COMPLEX 1
1-5
◆
1U-3700-5:WIRE COVER UNIT COMPLEX 1
2-1
◆
1U-3701-1:POWER AMP UNIT COMPLEX 1
2-2
◆
1U-3701-2:PRIMARY UNIT COMPLEX 1
2-5
◆
1U-3701-5:FFC COVER UNIT COMPLEX 1
2-6
◆
1U-3701-6:STYLE PIN UNIT COMPLEX 1
3-1
◆
1U-3702-1:P.SUPPLY UNIT COMPLEX 1
3-2
◆
1U-3702-2:CONNECT UNIT COMPLEX 1
3-3
◆
1U-3702-3:VOL AMP UNIT COMPLEX 1
3-4
◆
1U-3702-4:PRE CONNECT UNIT COMPLEX 1
4-1
◆
1U-3703-1:FLD UNIT COMPLEX 1
4-2
◆
1U-3703-2:FUNC. UNIT COMPLEX 1
4-3
◆
1U-3703-3:P.KEY UNIT COMPLEX 1
4-4
◆
1U-3703-4:JOINT UNIT COMPLEX 1
4-5
◆
1U-3703-5:TACT-1 UNIT COMPLEX 1
4-6
◆
1U-3703-6:TACT-2 UNIT COMPLEX 1
4-7
◆
1U-3703-7:VOL UNIT COMPLEX 1
4-8
◆
1U-3703-8:P.SW UNIT COMPLEX 1
4-9
◆
1U-3703-9:H/P UNIT COMPLEX 1
4-10
◆
1U-3703-10:CVBS UNIT COMPLEX 1
4-11
◆
1U-3703-11:V-CONN1 UNIT COMPLEX 1
4-12
◆
1U-3703-12:V-CONN2 UNIT COMPLEX 1
4-13
◆
1U-3703-13:232C UNIT COMPLEX 1
4-14
◆
1U-3703-14:EXT.CONNECT UNIT COMPLEX 1
5-1
◆
1U-3704-1:AUDIO UNIT COMPLEX 1
5-3
◆
1U-3704-3:FRONT IN UNIT COMPLEX 1
5-4
◆
1U-3704-4:MIC UNIT COMPLEX 1
5-5
◆
1U-3704-5:COMP-VIDEO UNIT COMPLEX 1
5-6
◆
1U-3704-6:S-VIDEO UNIT COMPLEX 1
5-13
◆
1U-3704-13:DSP REG. UNIT COMPLEX 1
5-14
◆
1U-3704-14:I POD UNIT COMPLEX 1
6
◆
1U-3737:DIGITAL UNIT COMPLEX 1
11 MAIN CHASSIS STEEL 1
13 BRACKET STEEL 2
14 R BRACKET BASE STEEL 1
15 SUPPORT BRACKET STEEL 1
16 FOOT ABS 4
17 RUBBER PAD PUR 4
18 P.W.B CATCHER PA-6 3
19 RADIATOR AL 1
23 PWB BRACKET (B) STEEL 2
24 RADIATOR BRACKET (F) STEEL 1
