Denon AVR-2807 Service Manual

125
AVR-2807
25 RADIATOR BRACKET (R) STEEL 1
26 CARD SPACER(L=10) PA-66 14
27 INSULATING SHEET(B) PVC 1
28 PUSH RIVET PA-6 3
29 BACK PANEL STEEL 1
30 LOCKING CARD SPACER PA-66 1
31
◆
TERMINAL ASS COMPLEX 1
32
◆
AM FM TUNER COMPLEX 1
33
◆
AC INLET COMPLEX 1
34 POWER TRANS COMPLEX 1
35 RUBBER SHEET CR 2
36 INSULATING SHEET(A) PVC 1
37 RUBBER FOAM CR 1
38 RUBBER SHEET CR 1
40 TOP COVER STEEL 1
41 SCREW COVER ABS 1
45
◆
DHCT-A3/C3 COMPLEX 14
51 INNER PANEL ABS 1
53 POWER LENS PMMA 1
54 INNER FRAME ABS 1
55 DOOR SHEET PVC 1
56 RUBBER SHEET CR 2
57 RUBBER SHEET CR 2
58 WINDOW PMMA 1
59
◆
P.KNOB ASSY(SUB) COMPLEX 1
60 CURSOR KNOB ABS 1
61 ENTER KNOB ABS 1
62
◆
GEAR DAMPER COMPLEX 1
63
◆
P.KNOB ASSY(MAIN) COMPLEX 1
64 SPACER PVC 1
65 DOOR STOPPER SUS304 1
66 FRONT CHASSIS STEEL 1
67 FRONT PANEL AL 1
68 DENON BADGE AL 1
69 LENS PMMA 3
70 DOOR ASS'Y AL+Ni-Form 1
71 HINGE (L) ABS 1
72 HINGE (R) ABS 1
73
◆
KNOB (M) ASS'Y COMPLEX 1
74
◆
KNOB (F) ASS'Y COMPLEX 1
75 FFC COVER PVC 1
77
◆
MINI TRANS COMPLEX 1
78
◆
CAPACITOR COMPLEX 2
79
◆
CAPACITOR COMPLEX 10
80 SAFETY COVER PC 1
81 COVER HOLDER POM 6
SCREW
100 3X8 CBTS (P)-Z STEEL 38
101 3X8 CBTS (S)-Z STEEL 19
102 3X8 CFTS (P)-Z STEEL 5
103 SPECIAL SCREW STEEL 3
104 3X6 CBTS(S)-Z STEEL 4
106 4X6 CBTS(S)-Z STEEL 4
Ref. No.
WEEE
MARK
Part Name MATERIAL Q'ty

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
