Denon AVR-2807 Service Manual

126
AVR-2807
107 3X6 CBTS(S)-B STEEL 26
107 3X6 CBTS(S)-B STEEL 25
108 3X8 CBTS (S)-B STEEL 8
109 3X10 CBTS (P)-Z STEEL 5
110 3X20 CBTS (P)-Z STEEL 3
111 3X8 CPTS(P)-Z STEEL 4
112 3X10 CBTS(B)-Z STEEL 17
114 3X10 CBTS(B)-B STEEL 5
115 4X8 CBTS(B)-B-3P STEEL 6
115 4X8 CBTS(B)-N-3P STEEL 6
116 FIXING SCREW STEEL 44
116 FIXING SCREW STEEL 43
117 3X16 CPTS(B) SW W STEEL 14
119 SPECIAL SCREW STEEL 1
120 9 NUT STEEL 2
Ref. No.
WEEE
MARK
Part Name MATERIAL Q'ty

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
