Denon AVR-2807 Service Manual

127
AVR-2807
Exploded view of AVR-2807 (E1C:China model) : MAIN UNIT
28
40
11
27
13
26
26
19
37
35
36 33
31
32
41
28
29
35
38
18
30
18
23
26
23
25
13
14
16
17
16
17
15
34
24
26
45
1-1
4-13
1-3
1-4
3-2
1-2
6
3-4
4-11
2-5
4-10
4-14
5-5
5-1
5-13
5-14
2-2
4-12
5-6
2-1
3-1
1-5
3-3
2-6
101
109
109
110
101
101
107
101
114
115
114
101
108
105
107
116
107
116
107
116
107
116
107
107
112
112
112
107
112
101
101
114
107
101
107
107
108
108
101
107
118
118
104
112
119
101
101
104
115
104
117
110
DHCT-C3
DHCT-A3
78
79
3-1
77
81
80
You have to remove the parts that marked
"WEEE mark " when the recycling processing.
(Europe model only)

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
