Denon AVR-2807 Service Manual

86
AVR-2807
EXPLODED VIEW (1/2) (MAIN UNIT)
28
40
11
27
13
26
26
19
37
35
36 33
31
32
41
28
29
35
38
18
30
18
23
26
23
25
13
14
16
17
16
17
15
34
24
26
45
1-1
4-13
1-3
1-4
3-2
1-2
6
3-4
4-11
2-5
4-10
4-14
5-5
5-1
5-13
5-14
2-2
4-12
5-6
2-1
3-1
1-5
3-3
2-6
101
109
109
110
101
101
107
101
114
115
114
101
108
105
107
116
107
116
107
116
107
116
107
107
112
112
112
107
112
101
101
114
107
101
107
107
108
108
101
107
118
118
104
112
119
101
101
104
115
104
117
110
DHCT-C3
DHCT-A3
77
76
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
