88
AVR-2807
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU : U.S.A. model(Black) EC : Canada model(Black)
E1C : China model(P.Silver) EUT : Taiwan R.O.C. model (P.Silver)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 nsp 00D 1U- 3700 K MAIN CPU UNIT EU,EC 1 *
1 nsp 00D 1U- 3700 M MAIN CPU UNIT EUT,E1C 1 *
1-1 - 1U-3700-1:MAIN CPU UNIT
1-2 - 1U-3700-2:DIGITAL IN UNIT
1-3 - 1U-3700-3:EXT IN/PREOUT UNIT
1-4 - 1U-3700-4:PRE CONNECT2 UNIT
1-5 - 1U-3700-5:WIRE COVER UNIT
2 nsp 00D 1U- 3701 K POWER AMP UNIT EU,EC 1 *
2 nsp 00D 1U- 3701 M POWER AMP UNIT EUT 1 *
2 nsp 00D 1U- 3701 N POWER AMP UNIT E1C 1 *
2-1 - 1U-3701-1:POWER AMP UNIT
2-2 - 1U-3701-2:PRIMARY UNIT
2-5 - 1U-3701-5:FFC COVER UNIT
2-6 - 1U-3701-6:STYLE PIN UNIT
3 00D 1U- 3702 K P.SUPPLY UNIT EU,EC 1 *
3 00D 1U- 3702 M P.SUPPLY UNIT EUT 1 *
3 00D 1U- 3702 N P.SUPPLY UNIT E1C 1 *
3-1 - 1U-3702-1:P.SUPPLY UNIT
3-2 - 1U-3702-2:CONNECT UNIT
3-3 - 1U-3702-3:VOL AMP UNIT
3-4 - 1U-3702-4:PRE CONNECT UNIT
4 nsp 00D 1U- 3703 K FRONT UNIT EU,EC 1 *
4 nsp 00D 1U- 3703 L FRONT UNIT EUT,E1C 1 *
4-1 - 1U-3703-1:FLD UNIT
4-2 - 1U-3703-2:FUNC. UNIT
4-3 - 1U-3703-3:P.KEY UNIT
4-4 - 1U-3703-4:JOINT UNIT
4-5 - 1U-3703-5:TACT-1 UNIT
4-6 - 1U-3703-6:TACT-2 UNIT
4-7 - 1U-3703-7:VOL UNIT
4-8 - 1U-3703-8:P.SW UNIT
4-9 - 1U-3703-9:H/P UNIT
4-10 - 1U-3703-10:CVBS UNIT
4-11 - 1U-3703-11:V-CONN1 UNIT
4-12 - 1U-3703-12:V-CONN2 UNIT
4-13 - 1U-3703-13:232C UNIT
4-14 - 1U-3703-14:EXT.CONNECT UNIT
5 nsp 00D 1U- 3704 K AUDIO/VIDEO UNIT EU,EC,EUT,E1C 1 *
5-1 - 1U-3704-1:AUDIO UNIT
5-3 - 1U-3704-3:FRONT IN UNIT
5-4 - 1U-3704-4:MIC UNIT
5-5 - 1U-3704-5:COMP-VIDEO UNIT
5-6 - 1U-3704-6:S-VIDEO UNIT
5-13 - 1U-3704-13:DSP REG. UNIT
5-14 - 1U-3704-14:IPOD UNIT
6 00D 1U- 3737 DIGITAL UNIT EU,EC 1 *
6 00D 1U- 3737 A DIGITAL UNIT EUT,E1C 1 *
11 nsp 00D 411 2089 012 MAIN CHASSIS 1 *
13 nsp 00D 412 4210 002 BRACKET 2
14 nsp 00D 412 5273 006 R BRACKET BASE 1
15 nsp 00D 412 4716 014 SUPPORT BRACKET 1
16 nsp 00D 104 0334 007 FOOT 4
17 nsp 00D 461 0385 001 RUBBER PAD 4
To Next Page
