Denon AVR-2807 Service Manual

128
AVR-2807
Exploded view of AVR-2807 (E1C:China model) : FRONT PANEL UNIT
51
53
54
55
56
56
57
57
58
59
60
61
62
63
64
65
66
75
67
68
69
70
71
72
73
74
100
100
102
102
102
100
100
100
100
100
100
100
100
100
111
100
100
101
100
101
102
103
103
120
120
100
101
4-4
4-1
4-2
4-3
4-8
4-9
5-3
5-4
4-7
4-54-6
H/P PLATE : Cut INNER PANEL
D/S PLATE : Cut INNER PANEL
100
You have to remove the parts that marked
"WEEE mark " when the recycling processing.
(Europe model only)

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
