Denon AVR-2807 Service Manual

90
AVR-2807
77 nsp 00D 449 0139 105 COVER HOLDER E1C,EUT 6
* nsp 00D 513 4104 000 FUSE CAUTION LABEL EU,EC 1
* nsp 00D 445 8004 007 WIRE CLAMPER 9
* nsp 00D 203 2440 018 2P VA CORD 1
* nsp 00D GEN 8176 LICENSE SUB ASSY 1 *
* nsp 00D 513 8266 009 DANGEROUS MARK EU,EC 1
* nsp 00D 513 1581 011 SERIAL NO. SHEET 1
* nsp 00D GEN 6881-2 RATING LABEL(T) EUT
* nsp 00D 415 0845 001 SP RIVET E1C,EUT 18
SCREW
100 nsp 00D 473 7500 015 3X8 CBTS (P)-Z 39
101 nsp 00D 473 7002 018 3X8 CBTS (S)-Z 19
102 nsp 00D 473 7500 028 3X8 CFTS (P)-Z 5
103 nsp 00D 477 0262 019 SPECIAL SCREW 3
104 nsp 00D 473 7002 005 3X6 CBTS(S)-Z 4
105 nsp 00D 473 7003 017 3X8 CFTS (S)-B 2
107 nsp 00D 473 7015 005 3X6 CBTS(S)-B 26
108 nsp 00D 473 7015 018 3X8 CBTS (S)-B 8
109 nsp 00D 473 7501 001 3X10 CBTS (P)-Z 5
110 nsp 00D 473 7501 030 3X20 CBTS (P)-Z 3
111 nsp 00D 473 7531 000 3X8 CPTS(P)-Z 4
112 nsp 00D 473 8034 030 3X10 CBTS(B)-Z EU,EC 18
112 nsp 00D 473 8034 030 3X10 CBTS(B)-Z E1C,EUT 17
114 nsp 00D 473 8034 098 3X10 CBTS(B)-B 5
115 00D 473 8064 000 4X8 CBTS(B)-B-3P EU,EC 6
115 00D 473 8064 013 4X8 CBTS(B)-N-3P E1C,EUT 6
116 00D 477 0064 107 FIXING SCREW 44
117 nsp 00D 477 0153 018 3X16 CPTS(B) SW W 14
118 nsp 00D 473 7004 016 4X6 CBTS(S)-Z 4
119 00D 471 8010 100 SPECIAL SCREW 1
120 - 9 NUT 2
WIRE
* nsp 00D 203 2437 047 2P VA-VA CON.CORD 1
* nsp 00D 203 5373 001 3P PH-PH CON.CORD 1
* nsp 00D 203 5374 000 3P PH-ZH CON.CORD 1
* nsp 00D 203 5375 009 3P PH-PH CON.CORD 1
* nsp 00D 203 5376 008 3P PH-PH CON.CORD 1
* nsp 00D 203 6634 008 4P PH-PH CON.CORD 1
* nsp 00D 203 8572 003 5P PH-PH CON.CORD 1
* nsp 00D 203 8573 002 5P PH-PH CON.CORD 1
* nsp 00D 204 0601 001 6P PH-PH CON.CORD 1
* nsp 00D 204 2999 009 7P PH-PH CON.CORD 1
* nsp 00D 204 3000 007 8P PH-ZH CON.CORD 1
* 00D 009 0269 000 15P FFC (1.25) 1
* 00D 009 0271 001 25P FFC CABLE(1.25) 1
* 00D 009 0271 014 17P FFC CABLE(1.25) 1
* 00D 009 0272 000 11P FFC CABLE(1.00) 1
* 00D 009 0272 013 18P FFC CABLE(1.00) 1
* nsp 00D 203 5377 010 3P ZH-ZH CON.CORD 1
* 00D 009 0269 013 25P FFC (1.25) 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
