Denon AVR-4306 Service Manual

87
AVR-4306/AVC-4320
C124 nsp 00D 257 0504 982 CC73CH1H470JT +1608
C125 nsp 00D 257 0516 954 CK73B1E104KT +1608
C126 00D 254 4573 949 CE04W1H010MT(RE3)
C127,128 00D 254 4574 922 CE04W1H101MT(RE3)
C129 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C301,302 00D 255 1264 908 CQ93M1H102JT(B)
C304,305 00D 255 1279 951 CQ93M1H104JT(B)
C306,307 nsp 00D 257 0516 954 CK73B1E104KT +1608
C381,382 nsp 00D 257 0516 954 CK73B1E104KT +1608
C391,392 nsp 00D 257 0516 954 CK73B1E104KT +1608
C401,402 00D 254 4574 906 CE04W1H330MT(RE3)
C403-406 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C407,408 00D 254 4574 906 CE04W1H330MT(RE3)
C409-412 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C413,414 00D 254 4574 906 CE04W1H330MT(RE3)
C415,416 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C417,418 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C419,420 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C422 00D 254 4574 906 CE04W1H330MT(RE3)
C424 00D 254 4574 906 CE04W1H330MT(RE3)
C425,426 00D 254 4577 945 CE04W1C101MT(RE3)
C427,428 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C429 nsp 00D 257 0516 941 CK73B1E473KT +1608
C430 00D 254 4573 949 CE04W1H010MT(RE3)
C431 nsp 00D 257 0516 941 CK73B1E473KT +1608
C432 nsp 00D 257 0516 954 CK73B1E104KT +1608
C433 nsp 00D 257 0516 941 CK73B1E473KT +1608
C701 nsp 00D 257 0509 929 CK73B1H102KT +1608
C702 00D 254 4302 945 CE04W1A330MT(SRE)
C703 nsp 00D 257 0516 954 CK73B1E104KT +1608
C704 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C705 nsp 00D 257 0516 954 CK73B1E104KT +1608
C706 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C707 00D 254 4305 900 CE04W1H0R1MT(SRE)
C708 nsp 00D 257 0516 954 CK73B1E104KT +1608
C709 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C710 00D 254 4305 968 CE04W1H010MT(SRE)
C711 nsp 00D 257 0516 954 CK73B1E104KT +1608
C712-714 00D 254 4305 900 CE04W1H0R1MT(SRE)
C715 nsp 00D 257 0516 954 CK73B1E104KT +1608
C716 00D 254 4299 906 CE04W1C100MT(SRE)
C717,718 nsp 00D 257 0516 954 CK73B1E104KT +1608
C722 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C723 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C724-726 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C805,806 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C819,820 nsp 00D 257 0507 934 CC73CH1H221JT +1608
C821,822 00D 254 4304 943 CE04W1V100MT(SRE)
C823 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C824,825 00D 254 4213 940 CE04W0J221MT(SRA)
C826 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C827,828 00D 255 1265 978 CQ93M1H223JT(B)
C829,830 00D 255 1265 907 CQ93M1H682JT(B)
C831,832 00D 254 4304 943 CE04W1V100MT(SRE)
C846 00D 254 4304 943 CE04W1V100MT(SRE)
C848 00D 254 4304 943 CE04W1V100MT(SRE)
C856,857 00D 254 4304 943 CE04W1V100MT(SRE)
C878,879 00D 254 4303 960 CE04W1E330MT(SRE)
C888 00D 254 4305 968 CE04W1H010MT(SRE)
C889,890 nsp 00D 257 0516 954 CK73B1E104KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
