Denon AVR-4306 Service Manual

88
AVR-4306/AVC-4320
OTHERS PARTS GROUP
AS101 nsp 00D 146 2348 008 FLD HOLDER
AS102,103 - BUS BAR
CW108 nsp 00D 205 0885 053 10P CON.SOCKET TUC-P
CW135 nsp 00D 205 1326 032 13P SOCKET(9120)
CW138 nsp 00D 205 0942 006 13P CON.SOCKET(TUC-P
CW143 nsp 00D 205 1326 045 14P SOCKET(9120)
CX021 nsp 00D 205 0581 069 2P VH-VH CON BASE
CX042 nsp 00D 205 0343 045 4P CONN.BASE(KR-PH)
CX056 nsp 00D 205 0234 057 5P EH SID CONN BASE
CX082 nsp 00D 205 0355 088 8P KR CON BASE(L)
CX102 nsp 00D 204 3002 005 10P KR-DS CON.CORD
CX108 nsp 00D 205 0884 054 10P CON.BASE TUC-P
CX110 00D 205 1377 007 11P FFC BASE(9610SB)
CX121 nsp 00D 205 0884 070 12P CON.BASE TUC-P
CX135,136 nsp 00D 205 1324 034 13P PIN HEADER(9120)
CX138 nsp 00D 205 0943 005 13P CON.BASE(TUC-P)
CX143,144 nsp 00D 205 1324 047 14P PIN HEADER(9120)
CX155-158 nsp 00D 205 0884 041 15P CON.BASE TUC-P
CX912,913 nsp 00D 205 1248 039 11P JE CON.PLUG
CY082 nsp 00D 204 3001 006 8P KR-DS CON.CORD
CY102 nsp 00D 205 0480 005 10P KR CON BASE(L)
CY251 00D 205 1052 018 25P FFC BASE (9604F)
FB101,102 nsp 00D 247 0018 905 RM73B--0R0KT +2125
FB701-710 nsp 00D 247 0018 905 RM73B--0R0KT +2125
FB713 nsp 00D 247 0018 905 RM73B--0R0KT +2125
FB714,715 nsp 00D 247 2018 903 RM73B--0R0KT +1608
JK301 00D 204 8217 031 H/P JACK (BK(AU))
JK401-405 00D 204 8721 006 2P PIN JACK(NI)
JK701,702 00D 204 8720 007 MINI JACK
JK703,704 00D 204 8649 007 MINI JACK (RD)
JK705 00D 205 1153 001 9P S SUB CONNECTOR
JK804,805 00D 204 8722 005 2P PIN JACK(NI)
S301 00D 212 5611 903 TACT SWITCH(TAPE H5)
! S302 00D 212 1030 009 POWER SWITCH (TV-5)
S331-345 00D 212 5611 903 TACT SWITCH(TAPE H5)
S347 00D 212 5611 903 TACT SWITCH(TAPE H5)
S349 00D 212 5611 903 TACT SWITCH(TAPE H5)
S371-373 00D 212 5611 903 TACT SWITCH(TAPE H5)
S381 00D 212 0373 000 ROT.ENCODER-EC16B
S391 00D 212 5611 903 TACT SWITCH(TAPE H5)
S392 00D 212 0373 000 ROT.ENCODER-EC16B
S393-395 00D 212 5611 903 TACT SWITCH(TAPE H5)
W303 nsp 00D 205 1034 007 M3 SCREW TERMINAL
W381 - 1P CONTACT ASSY
W391 - 1P CONTACT ASSY
nsp 00D 414 1038 005 SHIELD PLATE
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
