Denon AVR-4306 Service Manual

89
AVR-4306/AVC-4320
00D1U-3743 AUDIO/VIDEO P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3551 002 NJW1321FP1
IC102,103 00D 263 1225 906 NJM2581M-TE1
IC201-204 00D 262 3168 903 TC94A32F +C
IC205 00D 262 3556 900 TC9459BFG
IC206 00D 263 0615 902 BA15218F-DXE2 +C
IC207-210 00D 262 3555 901 SA5532ADR
IC211 00D 262 3556 900 TC9459BFG
IC212 00D 263 0615 902 BA15218F-DXE2 +C
IC301-304 00D 263 1082 903 TK15420MTL +C
IC305,306 00D 262 3447 909 TC4053BFT
IC307 00D 262 3446 900 TC4052BFT
IC308-311 00D 262 3445 901 TC4051BFT
IC312,313 00D 263 1082 903 TK15420MTL +C
IC401 00D 262 2725 004 TC9273N-015
IC403,404 00D 263 0615 902 BA15218F-DXE2 +C
IC406 00D 262 3347 009 TC94A46FG +C
IC407 00D 263 0896 909 NJM2068MD-TE1 +C
IC408 00D 263 1098 900 LM833MX +C
IC409-417 00D 263 0896 909 NJM2068MD-TE1 +C
IC501 00D 262 2919 001 TC9274N-017
IC701 00D 262 2827 902 MM74HC4053SJ +C
IC702 00D 262 1671 900 NJM2229M-TE1
IC703 00D 262 3450 006 M35015-***SP
IC704 00D 262 3447 909 TC4053BFT
IC705-707 00D 263 1082 903 TK15420MTL +C
IC708-710 00D 263 1197 908 BU4094BCFV-E2
IC916 00D 269 0221 006 GP1FM313RZ
IC917 00D 263 0615 902 BA15218F-DXE2 +C
TR101 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR102 00D 269 0144 905 DTC114YK-T146 +C
TR103 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR301 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR302,303 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR501-528 00D 273 0460 905 KTC2875B-RTK +C
TR701,702 00D 273 0464 901 KTC3875SGR-RTK +C
TR810 00D 273 0458 904 2SC/KTC3200BL-AT TRANSISTOR
TR811,812 00D 271 0301 903 2SA/KTA1268BL-AT
TR813 00D 274 0160 907 2SD2144STPU
TR814,815 00D 271 0301 903 2SA/KTA1268BL-AT
TR816 00D 273 0458 904 2SC/KTC3200BL-AT TRANSISTOR
TR901-904 00D 275 0100 902 2SK771-5-TB
D101,102 00D 276 0794 900 KDS160 +2125
D301,302 00D 276 0794 900 KDS160 +2125
D701 00D 276 0740 909 KDS184-RTK(K-COM) +C
D702 00D 276 0794 900 KDS160 +2125
D815 00D 276 0794 900 KDS160 +2125
D816-829 00D 276 0773 905 RB501V-40 +2125
D901,902 00D 276 0794 900 KDS160 +2125
D904,905 00D 276 0794 900 KDS160 +2125
ZD905-907 00D 276 0683 930 UDZS5.1B-TE17 +C
ZD908-911 00D 276 0829 901 NSAD500F-T1B
ZD912-917 00D 276 0833 900 ESD PROTECTOR(6802)
ZD921,922 00D 276 0829 901 NSAD500F-T1B
RESISTORS GROUP
R877 00D 241 2383 902 RD14B2E223JNBST
R924 00D 276 0833 900 ESD PROTECTOR(6802)
R926,927 00D 276 0833 900 ESD PROTECTOR(6802)
R929 00D 276 0833 900 ESD PROTECTOR(6802)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
