Denon AVR-4306 Service Manual

90
AVR-4306/AVC-4320
CAPACITORS GROUP
C107-109 nsp 00D 257 0516 954 CK73B1E104KT +1608
C110-113 00D 254 4573 981 CE04W1H100MT(RE3)
C114 nsp 00D 257 0516 954 CK73B1E104KT +1608
C115 00D 254 4573 981 CE04W1H100MT(RE3)
C116 nsp 00D 257 0516 954 CK73B1E104KT +1608
C117 00D 254 4573 981 CE04W1H100MT(RE3)
C118 nsp 00D 257 0516 954 CK73B1E104KT +1608
C119 00D 254 4573 981 CE04W1H100MT(RE3)
C120 nsp 00D 257 0516 954 CK73B1E104KT +1608
C121 00D 254 4573 981 CE04W1H100MT(RE3)
C122 nsp 00D 257 0516 954 CK73B1E104KT +1608
C123 00D 254 4573 981 CE04W1H100MT(RE3)
C124 nsp 00D 257 0516 954 CK73B1E104KT +1608
C125 00D 254 4577 945 CE04W1C101MT(RE3)
C126-131 nsp 00D 257 0516 954 CK73B1E104KT +1608
C132 00D 254 4573 981 CE04W1H100MT(RE3)
C133 nsp 00D 257 0516 954 CK73B1E104KT +1608
C134 00D 254 4573 981 CE04W1H100MT(RE3)
C135 nsp 00D 257 0516 954 CK73B1E104KT +1608
C136 00D 254 4573 981 CE04W1H100MT(RE3)
C137 nsp 00D 257 0516 954 CK73B1E104KT +1608
C138 00D 254 4577 945 CE04W1C101MT(RE3)
C139 00D 254 4573 949 CE04W1H010MT(RE3)
C140 nsp 00D 257 0516 954 CK73B1E104KT +1608
C141-146 00D 254 4577 945 CE04W1C101MT(RE3)
C147-153 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C154 00D 254 4574 906 CE04W1H330MT(RE3)
C155 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C156 00D 254 4574 906 CE04W1H330MT(RE3)
C157-161 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C162 00D 254 4574 906 CE04W1H330MT(RE3)
C163 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C164 00D 254 4574 906 CE04W1H330MT(RE3)
C165-168 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C169 nsp 00D 257 0516 941 CK73B1E473KT +1608
C170 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C172 nsp 00D 257 0507 934 CC73CH1H221JT +1608
C173 nsp 00D 257 0516 941 CK73B1E473KT +1608
C174 00D 254 4573 949 CE04W1H010MT(RE3)
C175 nsp 00D 257 0516 941 CK73B1E473KT +1608
C179,180 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C181,182 nsp 00D 257 0516 954 CK73B1E104KT +1608
C201,202 00D 254 4573 994 CE04W1H220MT(RE3)
C203,204 00D 254 4569 911 CE04W1E470MT(RE3)
C205-208 00D 254 4573 949 CE04W1H010MT(RE3)
C209,210 nsp 00D 257 0502 971 CC73CH1H5R0CT +1608
C211,212 00D 254 4573 981 CE04W1H100MT(RE3)
C213,214 00D 254 4573 994 CE04W1H220MT(RE3)
C215,216 00D 254 4569 911 CE04W1E470MT(RE3)
C217-220 00D 254 4573 949 CE04W1H010MT(RE3)
C221,222 nsp 00D 257 0502 971 CC73CH1H5R0CT +1608
C223,224 00D 254 4573 981 CE04W1H100MT(RE3)
C227,228 00D 254 4573 994 CE04W1H220MT(RE3)
C229,230 00D 254 4569 911 CE04W1E470MT(RE3)
C231-234 00D 254 4573 949 CE04W1H010MT(RE3)
C235,236 nsp 00D 257 0502 971 CC73CH1H5R0CT +1608
C237,238 00D 254 4573 981 CE04W1H100MT(RE3)
C239,240 00D 254 4573 994 CE04W1H220MT(RE3)
C241,242 00D 254 4569 911 CE04W1E470MT(RE3)
C243-246 00D 254 4573 949 CE04W1H010MT(RE3)
C247,248 nsp 00D 257 0502 971 CC73CH1H5R0CT +1608
C249,250 00D 254 4573 981 CE04W1H100MT(RE3)
C253,254 00D 254 4573 981 CE04W1H100MT(RE3)
C257-260 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C261-264 00D 254 4573 981 CE04W1H100MT(RE3)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
