Denon AVR-4306 Service Manual

91
AVR-4306/AVC-4320
C266,267 00D 254 4573 981 CE04W1H100MT(RE3)
C269-272 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C273-276 00D 254 4573 981 CE04W1H100MT(RE3)
C301,302 00D 254 4574 906 CE04W1H330MT(RE3)
C303-310 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C311-314 00D 254 4574 906 CE04W1H330MT(RE3)
C315-320 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C321 00D 254 4574 906 CE04W1H330MT(RE3)
C322-325 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C326-328 00D 254 4574 906 CE04W1H330MT(RE3)
C329-332 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C333,334 00D 254 4574 906 CE04W1H330MT(RE3)
C335,336 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C337,338 00D 254 4577 945 CE04W1C101MT(RE3)
C339 nsp 00D 257 0516 941 CK73B1E473KT +1608
C340 00D 254 4573 949 CE04W1H010MT(RE3)
C341 nsp 00D 257 0516 941 CK73B1E473KT +1608
C342 nsp 00D 257 0516 954 CK73B1E104KT +1608
C343 nsp 00D 257 0516 941 CK73B1E473KT +1608
C348,349 00D 254 4577 945 CE04W1C101MT(RE3)
C350,351 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C401,402 00D 254 4573 981 CE04W1H100MT(RE3)
C403,404 00D 254 4574 906 CE04W1H330MT(RE3)
C413,414 00D 254 4573 981 CE04W1H100MT(RE3)
C417,418 00D 254 4573 994 CE04W1H220MT(RE3)
C419,420 00D 254 4573 981 CE04W1H100MT(RE3)
C423,424 00D 254 4573 994 CE04W1H220MT(RE3)
C431-434 00D 254 4573 981 CE04W1H100MT(RE3)
C436,437 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C439-442 00D 254 4573 981 CE04W1H100MT(RE3)
C445,446 00D 254 4573 994 CE04W1H220MT(RE3)
C447 00D 254 4573 949 CE04W1H010MT(RE3)
C501,502 00D 254 4573 994 CE04W1H220MT(RE3)
C503 00D 254 4573 907 CE04W1H0R1MT(RE3)
C504,505 00D 254 4573 994 CE04W1H220MT(RE3)
C506 00D 254 4573 907 CE04W1H0R1MT(RE3)
C507,508 00D 254 4573 994 CE04W1H220MT(RE3)
C509 00D 254 4573 907 CE04W1H0R1MT(RE3)
C510,511 00D 254 4573 994 CE04W1H220MT(RE3)
C512 00D 254 4573 907 CE04W1H0R1MT(RE3)
C513,514 00D 254 4573 994 CE04W1H220MT(RE3)
C515 00D 254 4573 907 CE04W1H0R1MT(RE3)
C516,517 00D 254 4573 994 CE04W1H220MT(RE3)
C518 00D 254 4573 907 CE04W1H0R1MT(RE3)
C519,520 00D 254 4573 994 CE04W1H220MT(RE3)
C521 00D 254 4573 907 CE04W1H0R1MT(RE3)
C525,526 00D 254 4573 981 CE04W1H100MT(RE3)
C702,703 nsp 00D 257 0516 954 CK73B1E104KT +1608
C704,705 00D 254 4574 906 CE04W1H330MT(RE3)
C706 00D 254 4577 945 CE04W1C101MT(RE3)
C708 nsp 00D 257 0506 977 CC73CH1H121JT +1608
C709 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C710,711 nsp 00D 257 0503 925 CC73CH1H100DT +1608
C712 00D 255 1265 978 CQ93M1H223JT(B)
C713 00D 254 4573 978 CE04W1H4R7MT(RE3)
C714 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C715 00D 254 4573 949 CE04W1H010MT(RE3)
C716 00D 254 4573 981 CE04W1H100MT(RE3)
C717 00D 254 4577 945 CE04W1C101MT(RE3)
C718 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C719 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C720 00D 254 4573 949 CE04W1H010MT(RE3)
C721 00D 255 1279 935 CQ93M1H683JT(B)
C722 nsp 00D 257 0508 917 CC73CH1H471JT +1608 CAPACITOR
C723 nsp 00D 257 0510 918 CK73B1H332KT +1608
C724,725 nsp 00D 257 0504 940 CC73CH1H330JT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
