Denon AVR-4306 Service Manual

92
AVR-4306/AVC-4320
C726 00D 254 4577 945 CE04W1C101MT(RE3)
C727 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C728 00D 254 4573 981 CE04W1H100MT(RE3)
C729 nsp 00D 257 0509 929 CK73B1H102KT +1608
C730 nsp 00D 257 0509 945 CK73B1H122KT +1608
C731,732 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C733-735 00D 254 4577 945 CE04W1C101MT(RE3)
C736,737 00D 254 4574 906 CE04W1H330MT(RE3)
C738 00D 254 4573 981 CE04W1H100MT(RE3)
C739-741 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C743,744 nsp 00D 257 0516 954 CK73B1E104KT +1608
C745-750 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C824 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C825 00D 254 4573 978 CE04W1H4R7MT(RE3)
C826 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C827 00D 254 4573 952 CE04W1H2R2MT(RE3)
C908-910 nsp 00D 257 0516 954 CK73B1E104KT +1608
C911-913 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C914,915 nsp 00D 257 0516 954 CK73B1E104KT +1608
C916,917 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C918-921 nsp 00D 257 0516 954 CK73B1E104KT +1608
C922-924 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C925,926 nsp 00D 257 0516 954 CK73B1E104KT +1608
C927,928 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C929,930 nsp 00D 257 0516 954 CK73B1E104KT +1608
C931 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C940,941 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C942-944 00D 257 0521 949 CK73B1A474KT
C945 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C946,947 nsp 00D 257 0507 934 CC73CH1H221JT +1608
C948-951 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C953 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C954,955 00D 254 4196 944 CE04W1H010MT (SRA)
C957 00D 254 4305 968 CE04W1H010MT(SRE)
C958 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C959 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C960,961 00D 254 4305 968 CE04W1H010MT(SRE)
C962 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C963 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C967 nsp 00D 257 0516 954 CK73B1E104KT +1608
C968,969 00D 254 4305 968 CE04W1H010MT(SRE)
C970,971 nsp 00D 257 0516 954 CK73B1E104KT +1608
C972 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C973 nsp 00D 257 0516 954 CK73B1E104KT +1608
C974,975 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C977 nsp 00D 257 0516 954 CK73B1E104KT +1608
C978 00D 254 4464 906 CE67C0J101MT +REF
C979 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC401-410 nsp 00D 247 2018 903 RM73B--0R0KT +1608
CC413,414 nsp 00D 257 0507 976 CC73CH1H331JT +1608
CC415-426 nsp 00D 257 0507 976 CC73CH1H331JT +1608
CC427-432 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC433,434 00D 254 4573 981 CE04W1H100MT(RE3)
CC435-448 00D 254 4573 981 CE04W1H100MT(RE3)
CC465,466 00D 254 4574 906 CE04W1H330MT(RE3)
CC467-480 00D 254 4574 906 CE04W1H330MT(RE3)
CC481,482 00D 254 4573 981 CE04W1H100MT(RE3)
CC483,484 nsp 00D 257 0507 976 CC73CH1H331JT +1608
CC485,486 00D 254 4573 981 CE04W1H100MT(RE3)
CC489,490 00D 254 4574 906 CE04W1H330MT(RE3)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
