Basic Operation Basic Operation
28
ENGLISH
ENGLISH
Selecting the Dolby Digital and DTS Surround
mode (only with digital input)
Play a program source with the , mark.
•“ ” or “ ” lights, depending on the source.
Press SURROUND PARAMETER.
Press
DD HH
to select the item, then press
FF GG
to set.
Press [STANDARD] to select “STANDARD (Dolby/DTS
Surround)”.
3
6
5
4
Select an input source for which digital (COAXIAL,
OPTICAL etc.) is set ( page 49).
1
Press INPUT MODE to select “AUTO”.
2
D.COMP.:
The dynamic range is compressed. Select one of four modes: “OFF”,
“LOW”, “MID” (middle) or “HIGH”.
Effective source mode
Dolby Digital /
DTS (For DTS sources, only displayed for compatible software.)
LFE:
To play the various types of software properly, we recommend
setting to the values shown below.
•To play Dolby Digital software: “0 dB”
•To play DTS movie software: “0 dB”
•To play DTS music software: “–10 dB”
SB CH OUT:
Select the play mode or surround back channel playback method.
The “ ” or “ ” indicator lights.
(1) For multi-channel sources
SB OFF (OFF):
Not played.
NON MTRX:
Surround channel signal played.
MTRX ON:
Surround channel signal played with digital matrix processing.
ES MTRX:
DTS signal played with digital matrix processing.
ES DSCRT:
Signal included in DTS-ES discrete 6.1-channel sources played.
PL
IIx CINEMA:
Decoded in Dolby Pro Logic IIx Cinema mode, surround back signal
played.
Set the surround back speaker to “2spkrs” at “Speaker
Configuration” ( page 60).
PLIIx MUSIC:
Decoded in Dolby Pro Logic IIxMusic mode, surround back signal
played.
Set the surround back speaker to “1spkr” or “2spkrs” at
“Speaker Configuration” ( page 60).
(2) For 2-channel sources
OFF: Not played.
ON: Surround channel signal played.
CINEMA EQ.:
Use this if movie dialogues sound harsh to lower the treble sound.
Effective source mode
Dolby Pro Logic IIx / Dolby Pro Logic / Dolby Digital /
DTS Surround / DTS NEO:6
Press ENTER or SURROUND PARAMETER.
7
5
Example: Dolby Digital Example: DTS
Select “Default Yes” and press
FF
to reset all the settings.
¢ Dialog normalization function
This operates automatically when playing Dolby Digital sources.
This is a function for automatically correcting the standard signal level
for different program sources. The correction value can be checked by
pressing STATUS.
D
i
a
l
.
N
o
r
m
O
f
f
s
e
t
-
4
d
B
The numbers are the correction value when corrected to the standard level.
TONE:
Adjust the tone control.
Can be set in surround modes other than direct mode.
Can be set separately for the different surround modes. (Adjusted
together for the Dolby/DTS SURROUND modes.)
Room EQ:
Sets the equalizer individually for each surround mode.
Normal, Front, Flat:
See page 63.
Manual:
See page 57.
