Denon AVR-S730H Troubleshooting Guide

To check the HDMI Cable integrity, signal quality and resolution capability.
Procedure
1
Use ui to select "4 Cable Test" in the HDMI Diagnostics mode,
then press ENTER.
.
4 Cable Test
2
Connect the HDMI cable to be tested to HDMI1(CBL/SAT) and
MONITOR(1) OUT as shown in the figure, then select “Connect
the cable between HDMI1 IN and MONITOR(1) OUT, then press
ENTER".
.
–Connect the cab
.
HDMI1 (CBL/SAT)
MONITOR1
3
Select "Start", then press ENTER.
.
–CableTest Start
4
“Testing...” appears in the front panel display, and the test
starts.
.
Testing...
5
The AV Receiver shows Cable test result on the front panel
display.
To perform the cable test again, select “Retry” and press ENTER.
.
CABLE TEST FAIL
–Retry
Blink
6
To exit the cable test, remove the tested HDMI cable, then use i
to select "Exit" and press ENTER.
.
CABLE TEST FAIL
–Exit
Blink
Introduction
How to operate Cable Test Limit mode Log & EDID Troubleshooting
10

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
