Denon AVR-S730H Troubleshooting Guide

Trouble shooting Guide for HDMI Diagnostics (Video Test, Audio Test, Auto Test)
If an error ID is displayed when running tests from the Video Test/Audio Test/Auto Test menus, check in accordance with the flow of the appropriate error ID number.
If “PASS” is displayed even when the problem is not solved, refer to Audio/Video Flow “Other”.
ID Description
Video RX
V1-01
Cannot detect the HDMI cable connected to the AVR input terminal (as detection of 5V from Source Device).
V1-02
Cannot detect the HDMI signal from the source device at the AVR input terminal (as TMDS Rx PLL UnLock).
V1-03
Cannot detect the HDMI signal from the source device at the AVR input terminal (TMDS Rx PLL Lock, but SCDT(CKDT) OFF).
V1-04
Missing Video Info, or receiving Info Error (AVI Info does not exist).
V1-05
HDMI signal has video timing Error (Timing is not correct).
V1-06
Copyright Protection certification Error with Source Device. (HDCP Error).
V1-07
HDCP2.2/Stream ID Type mismatch (ie. Stream ID = 1,but Monitor's HDCP = V1.4).
V1-08
Mismatch between input resolution and the resolution that is supported by monitor.
V1-09
Audio/Video MUTE command from Source Device is always ON.
V1-10
Quality of HDMI Signal(TMDS) is bad.
Introduction How to operate Cable Test Limit mode Log & EDID Troubleshooting
20

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
