Denon AVR-S900W User Manual

Adjusting the picture quality for your
viewing environment (Picture Mode)
n
Supported input sources :
CBL/SAT / DVD / Blu-ray / Game / AUX1 /
AUX2 / Media Player / iPod/USB /
Online Music / CD
z
/ TV Audio
z
z
You can set the picture mode when an HDMI, component video or video
connector is assigned.
1
Press OPTION during video playback.
The option menu screen is displayed.
2
Use ui
to select “Picture Mode”, then press ENTER.
3
Use o p
to select picture mode.
Off: No picture quality adjustment is done with this unit.
Standard:
The standard mode suited for most living room
viewing environments.
Movie:
A mode suited for watching movies in a dark room
such as a theater room.
Vivid:
A mode that makes graphic images for games, etc.
brighter and more vivid.
Streaming: A mode suited for low bit rate video sources.
Custom: Adjusts the picture quality manually.
4
Press ENTER.
“Picture Mode” settings are stored for each input source.
Contents Connections Playback Settings Tips Appendix
110
Front panel Display Rear panel Remote Index

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
