Denon AVR-S900W User Manual

Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey
®
Setup.
0
If you change the speaker settings after performing “Audyssey
®
Setup”,
you will no longer be able to select Audyssey MultEQ
®
, Audyssey
Dynamic EQ
®
or Audyssey Dynamic Volume
®
. (v
p. 148 – 149)
0
“Manual Setup” can be used without changing the settings. Please set if
necessary.
Amp Assign
Select power amplifier usage method to match your speaker system.
See
“Speaker configuration andAmp Assignsettings” (v
p. 31) regarding
the speaker configuration and connection.
o
Assign Mode
Select how to use the power amp.
Surround Back:
Setting for 7.1-channel playback using
surround back speakers.
ZONE2
(Default):
Setting to assign the unit’s built-in power
amplifier for ZONE2 and output the audio
in stereo.
Front Height:
Setting for 7.1-channel playback using
front height speakers.
Contents Connections Playback Settings Tips Appendix
178
Front panel Display Rear panel Remote Index

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
