Denon AVR-S900W User Manual

.
Q0
o
Q2
Q1
i
H
System buttons
These perform playback related operations.
(v
p. 56)
0
Skip buttons (8, 9)
0
Play/pause button (1/3)
Tuning up / Tuning down buttons (TUNE +, –)
These select either FM broadcast or AM broadcast.
(v
p. 68)
I
QUICK SELECT buttons (1 – 4)
These call up settings registered to each button, such as input source,
volume level and sound mode settings. (v p. 127)
J
SOUND MODE buttons
These select the sound mode. (v p. 112)
0
MOVIE button
0
MUSIC button
0
GAME button
0
PURE button
K
Remote control signal transmitter
This transmits signals from the remote control unit. (v
p. 8)
L
SLEEP button
This sets the sleep timer.
(v
p. 125)
Contents Connections Playback Settings Tips Appendix
22
Front panel Display Rear panel Remote Index

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
