Displaying your desired video during
audio playback (Video Select)
This unit can display video from a different source on TV during audio
playback. You can set this for each input source.
n
Supported input sources :
iPod/USB / CD
z
/ Tuner / Online Music /
Bluetooth
z
This cannot be set when any of the HDMI, component video or video
connectors are assigned.
1
Press OPTION during audio playback.
The option menu screen is displayed.
2
Use ui to select “Video Select”, then press ENTER.
3
Use o p to select the Video Select mode.
Off
(Default):
Disable Video Select mode.
On: Enable Video Select mode.
4
If you selected “On” in step 3, press i and select
“Source”.
5
Use o p to select the input source for video you want
to play back, then press ENTER.
“Video Select” settings are stored for each input source.
Contents Connections Playback Settings Tips Appendix
109
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-S900W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-S900W and is the answer not in the manual?

Denon AVR-S900W Specifications

General IconGeneral
Channels7.2
HDMI Inputs8
HDMI Outputs2
Wi-FiYes
BluetoothYes
4K Ultra HD Pass-throughYes
Dolby AtmosYes
DTS:XNo
HDMI Pass-ThroughYes
Input Impedance47 kOhm
Input Sensitivity200 mV
THD at rated output0.08%
Signal-To-Noise Ratio98 dB
DAC Resolution24-bit / 192kHz
HDMI SwitchingYes
AirPlayYes
DLNAYes
Dimensions17.1 x 6.6 x 13.3 inches
Power Output90 W
Response Bandwidth10Hz-100kHz
Output Impedance / Channel6 Ohm
InputsHDMI
OutputsHDMI
Supported Audio FormatsMP3, WMA, AAC, FLAC, WAV
Supported Video Formats4K
Output Power / Channel90W (8 ohms, 20Hz-20kHz, 0.08% THD)
