Denon AVR-S900W User Manual

Output Settings
Makes settings for video output.
0
Can be set when “HDMI”, “COMP” or “VIDEO”
(v
p. 165) is assigned for each
input source.
0
“Resolution”, “Progressive Mode” and “Aspect Ratio” can be set when “i/p Scaler”
is set to anything other than “Off”.
0
“Output Settings” cannot be set when 4K signals are input.
0
“Video Conversion”, “i/p Scaler”, “Resolution”, “Progressive Mode” and “Aspect
Ratio” settings are stored for each input source.
o
Video Mode
Configure the video processing method to match the type of video
content.
Auto
(Default):
Process video automatically based on
the HDMI content information.
Game:
Always process video for game content.
Minimize the video delay when the video
is delayed compared to the button
operations on the controller of the game
console.
Movie:
Perform image processing that is suitable
for contents other than games.
If “Video Mode” is set to “Auto”, the mode is switched according to the input
contents.
Contents Connections Playback Settings Tips Appendix
158
Front panel Display Rear panel Remote Index

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
