Denon AVR-S900W User Manual

4
Enter the IP address of this unit in browser’s address
box.
For example, if the IP address of this unit is “192.168.100.19”, enter
“http://192.168.100.19”.
.
http://192.168.100.19
File
Edit View Tools HelpFavorites
5
When the top menu is displayed, click on the menu
item you want to operate.
.
MAIN ZONE
CBL/SAT
ZONE2
CBL/SAT
Load
AVR-S900W
AVR-S900W
Audio
Setup Menu
Video
Inputs
Speakers
Network
General
Save
0
You can use the “Save” and “Load” functions to store or recall various function
settings using web control from a PC.
0
To memorize settings, click “Save” on the Setup Menu screen.
0
To call up settings, click “Load” on the Setup Menu screen.
0
We recommend using one of the following web browsers.
Internet Explorer 10 and above
Mozilla Firefox 24 and above
Google Chrome 29 and above
Safari 5.x and above
Contents Connections Playback Settings Tips Appendix
131
Front panel Display Rear panel Remote Index

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
