Page #153 background imageLoading...
Page #153 background image
W9864G6KH-5 Block diagram
W9864G6KH
Publication Release Date: Nov. 12, 2013
- 6 - Revision A02
6. BLOCK DIAGRAM
CLK
CKE
A10
CLO CK
BUFFER
COMMA ND
DECO DER
ADDRESS
BUFFER
REFRESH
CO UNT ER
CO LUMN
CO UNT ER
CONTROL
SIGN AL
GENER ATOR
MODE
REGIST ER
COLUMN DECO DE R
SENSE AMPLIFIER
CELL ARRAY
BANK #2
COLUMN DECO DE R
SENSE AMPLIFIER
CELL ARRAY
BANK #0
COLUMN DECO DE R
SENSE AMPLIFIER
CELL A RRAY
BANK #3
DATA CONTRO L
CI RCUI T
DQ
BUFFER
COLUMN DECO DE R
SENSE AMPLIFIER
CELL ARRAY
BANK #1
NOT E:
The cell array configuration is 4096 * 256 * 16
A0
A9
BS0
BS1
CS
RAS
CAS
WE
A11
153
