Denon AVR-X2200W Service Manual

AVR-S910W/X2200W
LEVEL DIAGRAM
SURROUND ch
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
EXT IN
0dBFS
1.41Vrms
-
2dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-20dBFS(DIG.IN)
PCM or DD Config1
-26.5dBFS(A/D IN)
200mV
+30dB
SP OUT
4.48Vrms/8Ω
+
29dB
M
AX SIGNAL LEVEL
D
OLBY LIMIT LEVEL (ALLch-3dBFS)
+3dB
-26.5dBFS(DIG.IN)
DD Config2
-
2+6.5=4.5dB
＋
＋
SPEAKER
DSP
BD34704
GAIN
PCM1690
D/A
－
－
＋
PLD
101

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
