Denon AVR-X2200W Service Manual

NO
NO
NO
Is IC4140 (TOP268VG) damaged?
Is D4142, D4143, D4144, D4145 or
IC4140 damaged?
Repair the short circuited area on the
PCB.
Check the damaged parts.
Replace the damaged part.
Replace the damaged part.
Is the fuse (F4140) functioning proper-
ly?
Are there any short circuits caused by
the soldering on the PCB?
Are any parts damaged?
Replace the IC4140 (TOP268VG) and
D4142 / D4143 /D4144 / D4145.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
95

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
