1. FRONT PANEL ASSY
Proceeding : TOP COVER
FRONT PANEL ASSY
(1) Remove the screws.
(2) Remove the screws. Remove the CORD HOLDERs and connector wires. Remove the FFC.
View from the bottom
x6
FFC FFC
N1008
CP4400
CORD HOLDER
17
