Denon AVR-X2200W Service Manual

Check the connection environment
YES
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub connected to this
unit correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
When the static IP address is used, check that no other
devices have the same IP address and that the subnet
mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router and cong-
ure the settings correctly.
Check that there are no connection restrictions by MAC
addresses, etc.
NO
NO
NO
5. Network / Bluetooth / USB
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn on the pow-
er again.
NO
Check the connection environment
Checking the unit
YES
YES
Can the D3.3V2 output voltage (3.3 V)
to U1067 (DC-DC Conv.) be conrmed?
Can the voltage (5V) be conrmed between pin 2 and pin 5 of
CN4141?
Is D5V_POWER (U1018 uCOM 136 pin)
"Hi" ?
The circuit of D5V_POWER between
U1018 and U1067 are faulty.
The circuit around U1067 (DC-DC.
Conv.) is faulty.
The circuit between the AC inlet and CN4141 is faulty.
Check the SMPS PCB.
NO NO
NO
YES
90

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
