Denon AVR-X2200W Service Manual

FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT HDMI PCB
Ref. No. of EXPLODED VIEW : P 1
FRONT PCB
Ref. No. of EXPLODED VIEW : P 3
FUNCTION PCB
Ref. No. of EXPLODED VIEW : P 4
CNT PCB
Ref. No. of EXPLODED VIEW : P 5
F/H_GUIDE PCB
Ref. No. of EXPLODED VIEW : P 6
TOP COVER
TRANS
See "DISASSEMBLY"
7. TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : 13
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
Ref. No. of EXPLODED VIEW : P 7
GUIDE L PCB
Ref. No. of EXPLODED VIEW : P 17
TOP_GUIDE PCB
Ref. No. of EXPLODED VIEW : P 18
HDMI PCB
See "DISASSEMBLY"
3. HDMI PCB
and "EXPLODED VIEW"
HDMI PCB
Ref. No. of EXPLODED VIEW : P 13
VIDEO PCB
See "DISASSEMBLY"
4. VIDEO PCB
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : P 19
MAIN PCB
See "DISASSEMBLY"
5. MAIN PCB
and "EXPLODED VIEW"
MAIN PCB
Ref. No. of EXPLODED VIEW : P 9
SMPS PCB
See "DISASSEMBLY"
6. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : P 8
DISASSEMBLY
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "Precautions During Work" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
15

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
