4. Remote ID Setup Mode
4.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same
room.
4.2. Starting up
AVR-X2200W
· While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the power button to
turn on the power.
AVR-S910W
· While holding down buttons "
TUNER PRESET CH+
", "
TUNE -
" and "
TUNE +
" simultaneously, press the power button
to turn on the power.
Select the "
6. REMOTE ID
" using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
" button to conrm.
4.3. Operations
(1) When Remote ID Setup mode is activated, the following message is displayed.
FLD
R E M O T E I D ?
(2) Press the desired "
QUICK SELECT 1 - 4
" button.
Button Display
QUICK SELECT 1
R E M O T E I D 1
QUICK SELECT 2
R E M O T E I D 2
QUICK SELECT 3
R E M O T E I D 3
QUICK SELECT 4
R E M O T E I D 4
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4
" and the POWER button on the unit can be used in Remote ID Setup Mode.
b
The remote ID of the remote control supplied with this unit cannot be changed.
s
s
NOTE :
If the ID of the unit and remote control do not match, "
AVAMP
z
" appears on the display of the unit when the remote
control is used
(*: own remote control ID).
54

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
