Denon AVR-X2200W Service Manual

3.7. TUNER STEP mode
(E2 / E3 only)
3.3.1. Actions
This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed.
3.7.2. Starting up
AVR-X2200W
· While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the power button to
turn on the power.
AVR-S910W
· While holding down buttons "
TUNER PRESET CH+
", "
TUNE -
" and "
PRESET +
" simultaneously, press the power but-
ton to turn on the power.
Select the "
5. TUNER FRQ SET
" using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
" button to conrm.
3.7.3. Displays
Start up this unit in TUNER STEP mode, select the desired option using the "
TUNER PRESET CH +/-
" button, then enter
using the "
STATUS
" button.
The following information is displayed in the following order.
(a) AM9 kHz / FM50 kHz is selected
FLD
< A M 9 / F M 5 0 >
"
TUNER PRESET CH+
" "
TUNER PRESET CH-
"
(b) AM10 kHz / FM200 kHz is selected
FLD
< A M 1 0 / F M 2 0 0 >
"
STATUS
"
(c) Press the power button to turn off the power.
(d) Press the power button to turn on the power.
53

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
