Denon AVR-X2200W Service Manual

Connect the connectors correctly.
Repair the HDMI PCB.
NO
YES
4.3. Analog audio
No audio output.
Is a voltage of ± 8 V supplied to
INPUT PCB CN4006?
Is there an audio signal in INPUT PCB
CN401?
Reconnect the connectors correctly.
If the malfunctioning channel and function can be identied, check the correspond-
ing signal path.
Repair the ± 8 V power supply.
Repair the power amplier.
Is the connector correctly connected
to the HDMI PCB?
YES
NO
YES
NO
YES
89

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
