SMPS
SMPS PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4140-4146 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 7
! D4147 203050019501S AP01C-V1 52RE-AX FAST RECOVERY RECTIFIER DIODES K050000015000S 1
D4148 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4149 963204500210D S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
IC4140 943231102160S TOP268VG eDIP-12 OFF-LINE POWER SUPPLY IC J122268001010S 1 *
! IC4142 00D2623047008 PC123X2YFZ (DIP4P SHARP) K614123000010S 1
IC4143 212050010508S KIA2431AP,0.7W TO-92 J126243118010S 1
TR4140 943229500110S INK0010AC1 N-CH MOSFET SC-59 ISAHAYA J543001012010S 1 *
TR4142 963213500170D KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
U4000 943239100730S PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1
ZD4147-4149 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH E3, JP, S910 K06039R044522S 3
ZD4150 963202500970S ZJ27B-0.5W/5MA-52MM SEMTECH K06027R044522S 1 *
ZD4151-4156 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 6
ZD4157 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 1
ZD4158 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH E3, JP, S910 K06005R644522S 1
ZD4160 963202500340D ZJ15B-0.5W/5MA-52MM SEMTECH E2, E1C K06015R044522S 1
ZD4162-4164 963202500960S ZJ12B-0.5W/5MA-52MM SEMTECH K06012R044522S 3
RESISTOR GROUP
R4141,4142 nsp 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp 270K-J,1/16W-1608REEL E3, JP, S910 C20002746M160S 1
R4147 nsp 56K-J,1/16W-1608REEL E2, E1C C20005636M160S 1
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX E3, JP, S910 C00002256P520S 2
R4150 nsp 1M-J,1/5W-52RE-AX E3, JP, S910 C00001056P520S 1
R4151 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R4152 nsp 10K-J,1/16W-1608REEL E3, JP, S910 C20001036M160S 1
R4152 nsp 20K-J,1/16W-1608REEL E2, E1C C20002036M160S 1
R4153 nsp 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp 22K-F,1/16W-1608REEL C20002234M161S 1
R4161 00D2472041967 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4163 nsp 47-F,1/16W-1608REEL C20004704M161S 1 *
R4164 nsp 1M-J,1/5W-52RE-AX C00001056P520S 1
R4165 963125012630S 22-J,1W-5REEL C060022065050S 1
CAPACIITORS GROUP
C4000 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4001 nsp X7R0.015UF-K/50V-1608REEL D011153777160S 1
! C4140,4141 963134011730S DE1B3KX471KB4BL01 AC250V BULK MURATA D00847127H010S 2
! C4142 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 1
! C4143 nsp 0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARLI D02110407H010S 1
C4145 nsp X7R 0.047UF-K/50V-1608REEL D010473777160S 1 *
C4146 nsp X7R)0.01UF-K/50V-1608REEL D010103777160S 1
C4147 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
! C4148,4149 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 2
C4150 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4151 943134501590S 100UF-M/200V,16*20 BULK NHA SY E3, JP, S910 D04110108G000S 1
C4151 963134010200S 100UF-M/400V,18*31.5 BULK NHA SY E2, E1C D04110108K000S 1
C4152 963134010210S 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S DEHR33A102KB2B D00810207Q010S 1
C4154 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963133502500S DE1E3KX332MB4BN01F D00833208H010S 1 *
C4159 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4160 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C4161 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
C4163 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C4164,4165 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 2
C4166 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4169 963133502510S ST-0.0022UF-J/100V-5RE HPE222J2AP050T DAEHUNG D02022206C250S 1 *
OTHER PARTS GROUP
BKT4141 nsp AVRX2200WBKE3(DENON) BURRING HOLE SPCC t0.8+SN A4/ 4010210196100SV 1 *
BKT4143 nsp AVRX2200WBKE3(DENON) SPCC t0.8+SN plating A4/SCREW 4010210196000SV 1 *
BKT4144 nsp SR5010U1B SPTE t0.3/SMPS 3070210836000S 1 *
CN4141 nsp 150MM/6P YMH025-06=CKM2509HV-06 WH1007#22 L000151060180S 1 *
! CP4142 nsp LWB1143-02P 7.92MM HEADER,VER,2CKT L108011430210S 1
! F4140 963652010510S T2A/250V-IVBSUCPCcUR S506 E3, JP, S910 N751502001160S 1
! F4140 963652010500S T1.6A/250V-IVBSUCPCcUR S506 E2, E1C N751501601160S 1
! F4141 963652010520S T6.3A/250V-IVBSUCPCcUR S506 E3, JP, S910 N751506301160S 1
! F4141 963652010910S T3.15A/250V-IVBSUCPCcUR S506 E2, E1C N751503151160S 1
FC4140A nsp PI5.2-REEL G645000050010S 1
FC4140B,4141 nsp PI5.2-REEL G645000050010S
2
FC4141B nsp
PI5.2-REEL G645000050010S 1
! JK4140 963641011240S AC0152PPA66 AC INLET 2P_REV1.0 CCC E3, E2 G4300152P0001S 1
L4140 963111100420D SQ2014 27mH VERTICAL TYPE LINE FILTER E3, JP, S910
D320201405510VD3
1*
L4140 963111100470S SQ2014 50mH VERTICAL TYPE LINE FILTER E2, E1C
D320201405000VD3
1*
! RLY4140 963682100290D JZC-36FD/005-HLT 23.8*9.5*24.5mm G680060103030S 1
T4140 963102100540S EER2525 SW TRANSFORMER E060252505510V 1 *
CP4140 nsp PLUG YW396-03AV 2P E1C, JP, S910 L108396030010S 1
BKT4140 nsp AVRX2200WBKE3(DENON) BURRING HOLE SPCC t0.8+SN A4/ E1C, JP, S910 4010210196100SV 1 *
8
