Denon AVR-X2200W Service Manual

3.4. DIAGNOSTIC MODE (Service Path Check Mode)
3.4.1. Actions
This function is convenient for conrming problem paths in the product and checking the paths after repairing.
The Video and Audio paths can be checked.
The backup data is not rewritten.
3.4.2. Starting up
AVR-X2200W
While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the power button to turn on the power.
AVR-S910W
While holding down buttons "
TUNER PRESET CH +
", "
TUNE -
" and "
TUNE +
" simultaneously, press the power button to turn on the power.
Select "
1.SERVICE CHECK
", then press the "
STATUS
" button to activate the diagnostic mode.
The "
TUNED
", "
STEREO
" and "
RDS
" segments are lit in this mode.
3.4.3. Canceling diagnostic mode
Press the power button to turn off the power.
3.4.4. Selecting items to check
Press the
q
button to switch between video items and audio items.
Press the
w
or
e
button to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR
0
CURSOR
1
3.4.6. Audio system conrmation items
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1
Analog
A 0 1 : A N A L O G P A S S
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : DIRECT
Amp assign : Surround Back
MAIN ZONE : ON
ZONE2 : OFF
・ Analog input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
2
DIGITAL
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL (xed)
Sound mode : MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small/SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
・ Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Digital input ⇒ Pre OUT output (Front L/R, Center, Surround L/R, Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
3
DIGITAL
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : NETWORK
Input Mode : Auto
Sound mode : STEREO
Amp assign : ZONE2
MAIN ZONE : ON
ZONE2 : ON
・ Digital(PCM) input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
4
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : Surround Back
MAIN ZONE : ON
ZONE2 : OFF
・ HDMI input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Vol 60dB
Amp assign : Surround Back
Speaker Cong ALL Speaker=Small/SW=Yes(2ch)
MAIN ZONE : ON
ZONE2 : OFF
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Speaker output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60dB is the value when Relative settings are used. The value is -20 when Absolute settings are used)
g.01
g.02a
g.02b
g.03a
g.03b
g.04a
g.04b
g.05a
g.05b
30
