Denon AVR-X2200W Service Manual

1.3. File structure on USB Memory
Copy the update les to the USB memory with the following structure.
USB memory root
Model Name Model Area Product ID
AVR-X2200WE3 North America (E3) 000100830100
AVR-X2200WE2 Europe (E2) 000100830200
AVR-X2200WJP Japan (JP) 000100830400
AVR-X2200WE1C China (E1C) 000100830500
AVR-S910W North America (E3) 000100830700
+ rmwares
+ 000100XXXXXX
+ APLD.bin
+ DSP.bin
+ enc_update.xml
+ GUI.bin
+ IMG.bcd
+ MAIN.bin
+ SBL.bcd
1.4. Insert the USB memory into the USB port
NOTE : Remove the LAN cable from this unit when performing updates.
1.5. Start the update
AVR-X2200W
While holding down buttons "
TUNER PRESET CH +
" and "
STATUS
" simultaneously, press the power button to turn on
the power.
AVR-S910W
While holding down buttons "
ZONE2 SOURCE
" and "
TUNE +
" simultaneously, press the power button to turn on the
power.
1.6. Display during USB update
After around half minutes, display shows the following message.
Display
FLD
U S B U p d a t e S t a r t
1.7. Press the "ENTER" key on the remote control unit or this unit
Then start Firmware Update.
Display
FLD
U p d a t e F i l e C h e c k
Download firmware
in USB flash drive.
61

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
