Denon AVR-X2200W Service Manual

Input
CVBS / COMPONENT
A
Check the input signal to the VIDEO
DECODER.
Can a signal be conrmed at the follow-
ing points?
HDMI PCB
V : R2092
COMPONENT-Y : R2089
COMPONENT-Cb : R2091
COMPONENT-Cr : R2090
Check the connection between the
boards.
Input CVBS : Check B
Input COPONENT : Check C
Output COMPONENT NG : Check C-4
Output HDMI NG : See 3. HDMI/DVI
q
NO NO
YES
82

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
