Input

COMPONENT

Check the settings of each IC.

Are the following voltages

set?

HDMI PCB

N1039 - 11 pin : Lo (0 V)

N1039 - 15 pin : Hi (3.3 V)

Is the power voltage being

output correctly?

V+5V : C5029 : + side

V-5V : C5031 : - side

Is a signal being output from

the video amplier?

COMP-Y : J5032

COMP-CB : J5033

COMP-CR : J5000

• Check the connection between the FRONT CONNECTOR PCB and the VIDEO PCB.

• Check the soldering of CP3401 and CP5000 on the FRONT CONNECTOR PCB.

• Check the soldering of CN5000 on the VIDEO PCB.

• Check the soldering of JACK5001 on the VIDEO PCB.

Extend the HDMI PCB using

the jig.

HDMI PCB faulty.

Check the connection between the

FRONT CONNECTOR PCB and the

VIDEO PCB.

YES

These instructions refer to the VIDEO PCB unless otherwise specied.

• Check the IC5002 power voltage and check the soldering of the surrounding circuits.

• The pattern between IC5002 and JACK5002, JACK5003 are faulty.
